- Brand:
- Deye
- Model:
- SUN-3.6K-SG03LP1-EU
- Battery Voltage:
- 40VDC - 60VDC
- Battery Type:
- Lithium/Lead Acid
- Rated Output Power:
- 3600VA
- Max Output Current:
- 18A
- AC Voltage:
- 50/60Hz; 220/230Vac
- AC grid connection type:
- L/N/PE
- Max Efficiency:
- 97.6%
- MPPT efficiency:
- 99.9%
- Max PV Array Power:
- 4680W
- MPPT Voltage:
- 150~425V
- Independent MPPT Tracker:
- 2 Piece
- MPPT Tracker String:
- 1+1
- Protection Degree:
- IP65
- Dimensions (W / H / D):
- 330×580×232mm
- Net Weight:
- 20.5kg
SUN 3.6K-SG,hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence.
During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 3.6K-SG. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.
It equipped with RS485/CAN port for battery communication
